MODULES

Forzlux LED Modules are engineered for optimized thermal and photometric performance for a specific lighting task or application. Our modules are designed to meet OEM luminaire manufacturer’s cost targets while providing simple installation, maximum flexibility and modularity for a variety of luminaire sizes. Modules are available in a wide variety of configurations, shapes, CCT, CRI and monochromatic colors. Constant current versions are recommended for self-contained luminaires and maximum efficiency applications. Constant voltage versions are ideal for long-run and/or linear applications such as coves.

For assistance, please click on this email: sales@forzlux.com

Sorted by TYPICAL DIMENSIONS AND POWER, SMALLEST TO LARGEST

Constant Current unless otherwise specified. Photos not to scale, overall footprint dimensions specified

TURTLE FRIENDLY NON-PC AMBER (FWC COMPLIANT) NOW AVAILABLE ON MOST MODULES!



BB01CH1W, 150 Lumens0.45” x 0.61”Click for datasheet

BB01CH

1W, 160 Lumens

0.61” x 0.45”

Click for datasheet

BB03AA

3.9W, 617 Lumens

0.87” diameter

Click for datasheet

BB01CK1W, 150 Lumens0.88” squareClick for datasheet

BB01CK

1W, 160 Lumens

0.88” square

Click for datasheet

BB03AB

3.9W, 617 Lumens

1.0” x 0.4”

Click for datasheet

BB03FM3W, 460 Lumens1.1” diameterClick for datasheet

BB03FM

3.9W, 617 Lumens

1.15” diameter

Click for datasheet

BB03FK3W, 460 Lumens1.26” diameterClick for datasheet

BB03FK

3.9W, 617 Lumens

1.26” diameter

Click for datasheet

BB28VK-DTW

5-16W, 800-2330 Lumens

DIM-TO-WARM

1.38” square

Click for datasheet

BB30VK31.5W, 4500 Lumens1.38” squareClick for datasheet

BB30VK

31.5W, 4500 Lumens

1.38” square

Click for datasheet

BB04AM

3-11W, 150-770 Lumens

Monochromatic colors

1.48” square

Click for datasheet

BB06SB

9W, 300-1411 Lumens

1.74” diameter

Click for datasheet



BB09BU3W, 500 Lumens0.75” x 1.75”Click for datasheet

BB09BU

3.15W, 500 Lumens

1.75” x 0.75”

Click for datasheet

BB09BACONSTANT VOLTAGE THERMADJUST3W, 340 Lumens0.75” x 1.75”Click for datasheet

BB09BA

CONSTANT VOLTAGE THERMADJUST

3W, 340 Lumens

1.75” x 0.75”

Click for datasheet

BB12RD

13W, 2100 Lumens

1.62” square

Click for datasheet

BB24RF13W, 2054 Lumens1.62” squareClick for datasheet

BB24RF

13W, 2054 Lumens

1.62” square

Click for datasheet

BB14RC15W, 2040 Lumens2.17” square, 0.406” cutoutClick for datasheet

BB14RC

15W, 2040 Lumens

2.17” square

0.406” hole

Click for datasheet

BB03LL, BB06LL, BB09LL, BB12LL

4-16W, 500-2000 Lumens

2.75” or 5.5” or 8.25” or 11” x 0.5”

Click for datasheet

BB12SL

6.4W, 1100 Lumens

3” x 0.5”

Click for datasheet



BB33UP12W, 2000 Lumens3.46” diameter, 1.25” cutoutClick for datasheet

BB33UP

12W, 2000 Lumens

3.5” diameter

1.25” hole

Click for datasheet

BB132AH

38-77W, 6390 - 12570 Lumens

4.5” diameter

Click for datasheet

BB12TB6.5W, 1000 Lumens0.44” x 5.7”Click for datasheet

BB12TB

6.5W, 1000 Lumens

5.7” x 0.44”

Click for datasheet

BB40JT10.5W, 1800 Lumens4” x 6”Click for datasheet

BB40JT

10.5W, 1800 Lumens

6” x 4”, 0.65” hole

Click for datasheet


BB90WB49W, 7000 Lumens2.3” x 9.5”Click for datasheet

BB90WB

49W, 7000 Lumens

9.5” x 2.3”

Click for datasheet



BB30DQ10.5W, 1700 Lumens0.44” x 11.75”Click for datasheet

BB30DQ

10.5W, 1700 Lumens

11.75” x 0.44”

Click for datasheet

BB22TM

11.55W, 2035 Lumens

11” x 0.5” (2” section shown)

Click for datasheet

BB44TN

24W, 3800 Lumens

22” x 0.5” (2” section shown)

Click for datasheet

BB48TO

26W, 4100 Lumens

23.5” x 0.5” (2” section shown)

Click for datasheet

BB88TP

45W, 7670 Lumens

44” x 0.5” (2” section shown)

Click for datasheet




BB16PT

50W, 7700 Lumens

6” diameter, accepts Ledil STRADA-2X2 optics

Click for datasheet

BB80MB32W, 4900 Lumens9” diameter, 5.22” cutoutClick for datasheet

BB80MB

32W, 4900 Lumens

9” diameter, 5.22” hole

Click for datasheet
